| Code | Каталожный номер | Qty | Part name | Applied S/N range | ICA | Наличие на складе |
| 001 | 1136500681 | 1 | PUMP ASM; WATER,W/GASKET | 198808- | ||
| 003 | 1136140170 | 1 | GASKET; PUMP TO C/BL | 199204-199602 | A | |
| 003 | 1136140181 | 1 | GASKET; PUMP TO C/BL | 199603- | ||
| 004 | 1878121511 | 1 | REPAIR KIT; WATER PUMP | 198808- | ||
| 007(C) | 1136411850 | 1 | PULLEY; WATER PUMP | 198808- | ||
| 009 | 9091801680 | 1 | RING; SNAP,WATER PUMP | 198808- | ||
| 010 | 1098002790 | 3 | BEARING; WATER PUMP | 198808- | ||
| 011 | 1136340420 | 1 | SPACER; BRG,WATER PUMP | 198808- | ||
| 016(A) | 1096256180 | 1 | SEAL; OIL,WATER PUMP | 198808- | ||
| 016(B) | 1096256170 | 1 | SEAL; OIL,WATER PUMP | 198808- | ||
| 017 | 8943950360 | 1 | SEAL UNIT; WATER PUMP | 198808-200009 | A | |
| 017 | 8943920900 | 1 | SEAL UNIT; WATER PUMP | 200010- | ||
| 018 | 1136210590 | 1 | IMPELLER; WATER PUMP | 198808- | ||
| 024(A) | 0501408350 | 1 | BOLT; WATER PUMP | 199005-200512 | A | |
| 024(A) | 0506408350 | 1 | BOLT; WATER PUMP | 200601- | ||
| 024(B) | 0501408450 | 6 | BOLT; WATER PUMP | 199005-200906 | C | |
| 024(B) | 0506408450 | 6 | BOLT; WATER PUMP | 200907- | ||
| 024(C) | 0168060950 | 2 | BOLT; WATER PUMP | 199005- | ||
| 025 | 1136420460 | 1 | CENTER; WATER PUMP | 198808- | ||
| 029 | 1136310900 | 1 | SHAFT; WATER PUMP | 198808- | ||
| 054 | 0280810700 | 6 | BOLT; PULLEY | 198808-200512 | A | |
| 054 | 0280510700 | 6 | BOLT; PULLEY | 200601- | ||
| 055 | 1136190460 | 1 | NOZZLE; OIL FEED,WATER PUMP | 198808- | ||
| 072 | 1096233420 | 1 | GASKET; PUMP TO THERMO HSG | 198808- | ||
| 132 | 9091605100 | 2 | WASHER; PL,WATER PUMP | 198808-200605 | A | |
| 132 | 0916105100 | 2 | WASHER; PL,WATER PUMP | 200606- |
