| Code | Каталожный номер | Qty | Part name | Applied S/N range | ICA | Наличие на складе |
| 1(J) | 1113605532 | 1 | PAN ASM; OIL | 199211 - | |
| 2(B) | 1117602850 | 1 | GAUGE; OIL LEVEL | 199211 - | |
| 5 | 1096230570 | 1 | GASKET; PLUG,OIL DRAIN | 199211 - | |
| 6 | 9096620120 | 1 | PLUG; OIL DRAIN | 199211 - | |
| 8(A) | 1117663701 | 1 | TUBE; GUIDE,OIL LEVEL GAUGE | 199702 - | |
| 8(A) | 9096620121 | 1 | TUBE; GUIDE,OIL LEVEL GAUGE | 199211 - 199701 | |
| 9(A) | 5096230020 | 2 | GASKET; GUIDE TUBE,OIL LEVEL GAUGE | 199211 - | |
| 16 | 1113670961 | 1 | GASKET; OIL PAN TO C/BL | 199211 - 199510 | C |
| 16 | 1113671000 | 1 | GASKET; OIL PAN TO C/BL | 199511 - | |
| 23(A) | 0500408180 | 32 | BOLT; OIL PAN | 199211 - | |
| 109 | 1824800280 | 1 | SWITCH; OIL LEVEL | 199211 - 199410 | C |
| 109 | 8971193581 | 1 | SWITCH; OIL LEVEL | 199411 - 199411 | |
| 109 | 9096620122 | 1 | SWITCH; OIL LEVEL | 199412 - | |
| 110 | 1096233550 | 1 | GASKET; SW,OIL LEVEL | 199211 - 199411 | |
| 110 | 9096620123 | 1 | GASKET; SW,OIL LEVEL | 199412 - | |
| 111 | 5113690720 | 1 | SPACER; SW,OIL LEVEL | 199211 - 199411 | |
| 111 | 9096620124 | 1 | SPACER; SW,OIL LEVEL | 199412 - | |
| 112 | 0501406280 | 3 | BOLT; SW,OIL LEVEL | 199211 - 199701 | A |
| 112 | 0280806250 | 3 | BOLT; SW,OIL LEVEL | 199702 - | |
| 189 | 9091105080 | 1 | NUT; GUIDE | 199211 - | |
| 191(A) | 9091505080 | 1 | WASHER; LK,GUIDE TUBE,OIL LEVEL GAUGE | 199211 - | |
