Code | Каталожный номер | Qty | Part name | Applied S/N range | ICA | Наличие на складе |
002 | 1113415935 | 1 | HOUSING; FLYWHEEL | 200006- | |
018 | 1096234640 | 1 | GASKET; BRG CASE,DRIVE SHAFT | 200006- | |
019 | 0281812000 | 1 | BOLT; BRG CASE | 200006-200512 | |
019 | 0281512000 | 1 | BOLT; BRG CASE | 200601- | |
020 | 0911501100 | 2 | NUT; BRG CASE | 200006-200602 | |
020 | 0911502120 | 1 | NUT; BRG CASE | 200006-200602 | |
020 | 0911801100 | 2 | NUT; BRG CASE | 200603- | |
020 | 0911802120 | 1 | NUT; BRG CASE | 200603- | |
029 | 9080555160 | 1 | KEY; COUPLING | 200006- | |
032 | 8970287481 | 1 | GASKET; GEAR CASE TO C/BL | 200006- | |
035 | 8943961991 | 1 | SEAL; OIL,CRANKSHAFT FRT | 200006-200112 | A |
035 | 8976023783 | 1 | SEAL; OIL,CRANKSHAFT FRT | 200201- | |
043 | 1093021120 | 1 | STUD; BRG COVER | 200006- | |
051 | 0280808350 | 13 | BOLT; GEAR CASE COVER | 200006-200512 | |
051 | 0280508350 | 13 | BOLT; GEAR CASE COVER | 200601- | |
062(A) | 0280808140 | 3 | BOLT; COVER | 200006- | |
062(B) | 0280808200 | 3 | BOLT; COVER | 200006-200512 | |
062(B) | 0280508200 | 3 | BOLT; COVER | 200601- | |
109 | 9113276020 | 1 | POINTER; TIMING | 200006- | |
175 | 8943706370 | 1 | SEAL; OIL,CR/SHF,RR | 200006-200112 | A |
175 | 8976023790 | 1 | SEAL; OIL,CR/SHF,RR | 200201- | |
177 | 0280806160 | 1 | BOLT; SENSOR | 200006-200512 | |
177 | 0280506160 | 1 | BOLT; SENSOR | 200601- | |
211 | 8943939950 | 1 | BOLT; HSG | 200006- | |
211 | 0168062600 | 1 | BOLT; HSG | 200006-200512 | |
211 | 0281810500 | 1 | BOLT; HSG | 200006-200512 | |
211 | 9016662700 | 11 | BOLT; HSG | 200006-200512 | |
211 | 0168562600 | 1 | BOLT; HSG | 200601- | |
211 | 0169562700 | 11 | BOLT; HSG | 200601- | |
211 | 0281510500 | 1 | BOLT; HSG | 200601- | |
224 | 9044114350 | 2 | STUD; STARTER | 200006-200604 | |
224 | 0440114350 | 2 | STUD; STARTER | 200605- | |
225 | 8943965120 | 4 | STUD; OIL PAN | 200006- | |
228 | 9944112350 | 1 | STUD; AIR CMPR | 200006-200604 | |
228 | 0440112350 | 1 | STUD; AIR CMPR | 200605- | |
241 | 8943931401 | 12 | WASHER; PL,HSG | 200006- | |
264 | 9944112351 | 1 | NUT; COVER | 200006-200602 | |
264 | 9944112352 | 1 | NUT; COVER | 200603- | |
268 | 1113211601 | 1 | COVER; FRT | 200006- | |
275 | 1113270501 | 1 | POINTER; TIMING CHECK HOLE | 200006- | |
290 | 1113491570 | 1 | PLUG; SENSOR HOLE | 200101-200205 | |
290 | 8971019740 | 1 | PLUG; SENSOR HOLE | 200206- | |
356 | 8943941860 | 1 | GASKET; COVER | 200006- | |
404 | 8943916430 | 1 | CASE ASM; BRG,INJ PUMP | 200006- | |
405 | 1096255760 | 1 | SEAL; OIL,BRG CASE | 200006- | |
479 | 1096235700 | 1 | GASKET; COVER | 200006- | |
480(A) | 0281812700 | 3 | BOLT; COVER | 200006-200512 | |
480(A) | 0281512700 | 3 | BOLT; COVER | 200601- | |
480(B) | 0280806120 | 1 | BOLT; COVER | 200006-200512 | |
480(B) | 0280506120 | 1 | BOLT; COVER | 200601- | |
480(C) | 0280808120 | 1 | BOLT; COVER | 200006-200012 | |
487(A) | 8943945131 | 1 | COVER; HOLE | 200006-200805 | C |
487(A) | 8980238241 | 1 | COVER; HOLE | 200806- | |
487(B) | 8976014201 | 1 | COVER; HOLE | 200006- | |
487(C) | 1117491900 | 1 | COVER; HOLE | 200006-200012 | |
487(D) | 1117491840 | 1 | COVER; HOLE | 200006- | |
