| Code | Каталожный номер | Qty | Part name | Applied S/N range | ICA | Наличие на складе |
| 001 | 8972523211 | 1 | PIPE; OIL,INJ PUMP TO C/BL | 198911- | |
| 002(A) | 9099062051 | 1 | BOLT; EYE,OIL PIPE | 198911- | |
| 002(B) | 1096750810 | 1 | BOLT; EYE,OIL PIPE | 199912- | |
| 003 | 9095714100 | 2 | GASKET; EYE BOLT,OIL PIPE | 198911- | |
| 003 | 1096300840 | 2 | GASKET; EYE BOLT,OIL PIPE | 199912- | |
| 026(B) | 8941310603 | 1 | PIPE; OIL,PUMP TO C/BL | 198911- | |
| 028 | 9099211880 | 2 | GASKET; OIL PIPE | 198911- | |
| 037(D) | 8972221220 | 1 | PIPE; OIL,FILTER TO COOLER | 198911- | |
| 040(A) | 0501408450 | 4 | BOLT; OIL PIPE | 199111-200907 | A |
| 040(A) | 0506408450 | 4 | BOLT; OIL PIPE | 200908- | |
| 040(B) | 0500408350 | 2 | BOLT; OIL PIPE | 198911-199902 | A |
| 040(B) | 0280808200 | 1 | BOLT; OIL PIPE | 198911-200512 | A |
| 040(B) | 0280808300 | 2 | BOLT; OIL PIPE | 199903-200512 | A |
| 040(B) | 0280508200 | 1 | BOLT; OIL PIPE | 200601- | |
| 040(B) | 0280508300 | 2 | BOLT; OIL PIPE | 200601- | |
| 044 | 0280808120 | 1 | BOLT; CLIP,OIL PIPE | 198911-200512 | A |
| 044 | 0286810300 | 1 | BOLT; CLIP,OIL PIPE | 198911-200512 | A |
| 044 | 0280508120 | 1 | BOLT; CLIP,OIL PIPE | 200601- | |
| 044 | 0286510300 | 1 | BOLT; CLIP,OIL PIPE | 200601- | |
| 047 | 1096234620 | 1 | GASKET; OIL PIPE | 198911- | |
| 047 | 8970265900 | 1 | GASKET; OIL PIPE | 198911- | |
| 048 | 1097006952 | 1 | CLIP; OIL PIPE | 200006- | |
| 063(B) | 8972221201 | 1 | PIPE; OIL,TURBOCHARGER FEED | 198911- | |
| 087(A) | 9099211881 | 2 | GASKET; JOINT BOLT | 200001- | |
| 116 | 9095720100 | 2 | GASKET; CAP NUT,OIL PIPE | 198911- | |
| 142 | 9098440220 | 1 | NUT; CAP,OIL PIPE,INJ PUMP TO C/BL | 198911- | |
| 232 | 5123790010 | 1 | SPACER; OIL PIPE CLIP | 198911- | |
| 352 | 9099211882 | 1 | BOLT; CLIP | 199908-200512 | A |
| 352 | 9099211883 | 1 | BOLT; CLIP | 200601- | |
| 436 | 1096750770 | 1 | BOLT; JOINT | 200001-200612 | A |
| 436 | 8973722380 | 1 | BOLT; JOINT | 200701- | |
| 542 | 8972543692 | 1 | PIPE: VAC,BOOST | 199908- | |
| 567 | 1097004440 | 2 | CLIP; PIPE | 200103- | |
