Code | Каталожный номер | Qty | Part name | Applied S/N range | ICA | Наличие на складе |
1 | 8971242340 | 1 | PIPE; OIL,INJ PUMP TO C/BL | 198911- | |
002(A) | 9099062051 | 1 | BOLT; EYE,OIL PIPE | 198911- | |
002(B) | 1096750810 | 1 | BOLT; EYE,OIL PIPE | 199912- | |
3 | 9095714100 | 2 | GASKET; EYE BOLT,OIL PIPE | 198911- | |
3 | 1096300840 | 2 | GASKET; EYE BOLT,OIL PIPE | 199912- | |
026(B) | 8941310603 | 1 | PIPE; OIL,PUMP TO C/BL | 198911- | |
28 | 9099211880 | 2 | GASKET; OIL PIPE | 198911- | |
037(D) | 8972221220 | 1 | PIPE; OIL,FILTER TO COOLER | 198911- | |
040(A) | 501408450 | 4 | BOLT; OIL PIPE | 199111-200907 | A |
040(A) | 506408450 | 4 | BOLT; OIL PIPE | 200908- | |
040(B) | 500408350 | 2 | BOLT; OIL PIPE | 198911-199902 | A |
040(B) | 280808200 | 1 | BOLT; OIL PIPE | 198911-200512 | A |
040(B) | 280808300 | 2 | BOLT; OIL PIPE | 199903-200512 | A |
040(B) | 280508200 | 1 | BOLT; OIL PIPE | 200601- | |
040(B) | 280508300 | 2 | BOLT; OIL PIPE | 200601- | |
44 | 280808120 | 1 | BOLT; CLIP,OIL PIPE | 198911-200512 | A |
44 | 286810300 | 1 | BOLT; CLIP,OIL PIPE | 198911-200512 | A |
44 | 280508120 | 1 | BOLT; CLIP,OIL PIPE | 200601- | |
44 | 286510300 | 1 | BOLT; CLIP,OIL PIPE | 200601- | |
47 | 1096234620 | 1 | GASKET; OIL PIPE | 198911- | |
47 | 8970265900 | 1 | GASKET; OIL PIPE | 198911- | |
48 | 1097006952 | 1 | CLIP; OIL PIPE | 200006- | |
063(B) | 8972221201 | 1 | PIPE; OIL,TURBOCHARGER FEED | 198911- | |
116 | 9095720100 | 2 | GASKET; CAP NUT,OIL PIPE | 198911- | |
142 | 9098440220 | 1 | NUT; CAP,OIL PIPE,INJ PUMP TO C/BL | 198911- | |
232 | 5123790010 | 1 | SPACER; OIL PIPE CLIP | 198911- | |
